Description
Brand: SMART
Package contents: 50
EAN code: 5902134703947
Chapter: Synthetic
Matter: Nylon PA6
Packaging type: Window box
Surface: zinc plated Cr3+
Kind: With panel screws
Technical specifications
drilling diameter (d0): 8
d2: 8.0
screw diameter (ds): 5
drilling depth (h1): 55
effective anchoring depth (hef): 40
l2: 40
screw length (ls): 60
thickness to be fixed (tfix): 20
diameter: 8.00
length: 40.00
